Mitsubishi Electric non VRF – CoolMaster EDGE Indoor line connection

Yoram
Last update:

This article applies to the CoolMaster EDGE

Mitsubishi Electric – non VRF line connection

Maximum indoor per line: 50

  • Supported device line number: L2
  • No line polarity required
  • Cable type – Follow Mitsubishi Electric's installation instructions
  • Set line type in the EDGE device to:  ME
  • In Case the line is not mixed with VRF units , set the Edge line DC power on,
    Caution – Apply power from the coolmaster Edge only if the line is free of power
  • Each Indoor adapter must be set with unique address for control
  • Follow ME instructions on how to set up adapters address
